Beans Diesel 280002 Multi-Function Fuel Tank Sump

Beans Diesel 280002 Multi-Function Fuel Tank Sump

The Beans Diesel 280002 Multi-Function Fuel Tank Sump is a USA-made upgrade that solves common aftermarket fuel-system problems. Machined from a single piece of 6061 billet aluminum, it pulls fuel from the lowest point in the tank so you can run well below 1/8 tank without drawing air. It also quiets high-flow lift pumps (AirDog, FASS, and similar) and reduces strain on the pump.

The original single-hole design needs only a 3-inch hole and one bolt. A “Pacman” backer ring installs from inside the tank without dropping it. A single O-ring plus O-ring-boss (ORB) fittings create a leak-resistant seal—unlike traditional pipe-thread fittings.

Versatile configurations

• Supply + return
• Single outlet (plug included)
• Dual outlets for high-horsepower trucks that need extra fuel volume

It works on gasoline or diesel and on metal or plastic tanks that have at least a 4-inch flat area. An internal sediment bowl helps keep debris out of the filter, and a stainless 1/4-NPT drain plug makes future tank service or draining easy.

Kit includes

• Billet aluminum sump body
• Pacman in-tank backer ring
• 3-inch hole saw (plastic tanks; metal tanks need a metal hole saw)
• Stainless bolt, sealing washer, and O-ring
• Two –8 ORB to 1/2-inch QDC/push-lock fittings
• One –8 ORB plug for single-outlet use
• 1/4-NPT stainless drain plug

Designed and manufactured in Woodbury, Tennessee, the 280002 is a straightforward, reliable solution for anyone adding a high-flow lift pump or wanting to use every gallon in the tank.
